CPH50 (Home Flex)
The ChargePoint Home Flex is a Level 2 home charger that is fast, flexible, reliable and smart. Compared to a standard wall outlet, it can charge up to 50 amps, which is nine times faster. This enables users to increase the range of their electric vehicle by up to 37 miles per hour while using up to 9.6 kW of power. Drivers can change the charging speed from 16 amps to 50 amps to fit their demands and the capacity of their residence. Its robust, weatherproof construction guarantees dependable operation in a variety of environmental circumstances, offering small companies and homeowners a dependable EV
Electric Vehicle charging option.
A charging cable measuring 7010.4 mm (23 ft) is included with the ChargePoint Home Flex charger. A mobile app allows users to alter the output amperage to 16 A, 24 A, 32 A, 40 A, 48 A, and 50 A. Its maximum AC power output rating is 12 kW (240 V AC * 50 A). Plug-Out Detection, Open Safety Ground Detection, and Ground Fault Detection are among the safety and connection features that come with the charger. Additionally, it supports 2.4/5 GHz Wi-Fi Wireless Fidelity (802.11 a/b/g/n) enabling connection to local area networks.
Refer to the following documents for more information:
