Prepare for Installation

Follow all instructions provided in this chapter to prepare for installation.

General Instructions and Notes

Do not install or service the charging station in inclement weather. If you work in snow, rain, or wind, you must use a weather-proof shelter that covers all boxes and components.
Warranty Limitation
  • If the charging station is not installed, commissioned, or serviced by a ChargePoint certified technician using a ChargePoint-approved method, it is excluded from all ChargePoint and other warranties and ChargePoint is not responsible.
  • You must be a licensed electrician and complete training at https://www.chargepoint.com/partners/training-certification to become ChargePoint certified and to access ChargePoint's web-based installer tools or ChargePoint Installer app.
Use low torque settings when working with power tools during installation or servicing. Over-torquing can damage the equipment.
While installing fasteners inside a product enclosure, make sure not to drop the fasteners inside conduit openings. You may use conduit caps or covers to temporarily cover the conduit openings.
Ensure that the installation complies with all applicable codes and ordinances.

Check Site Readiness

Complete this checklist before you install Express Solo.

Site Readiness Checklist

Express Solo Site Readiness Checklist
1.

The concrete mount surface is smooth and level.

☐
2.

The concrete pad or concrete surface meets the mounting specifications given in the Express Solo Site Design Guide and/or is inspected and approved by a structural engineer for the product dimensions and weight (as given in the Express Solo Site Design Guide).

 ☐
3.

Wires and conduits meet the requirements given in the site drawings.

 ☐
4.

The electrical equipment is installed and labeled in accordance with the applicable national electrical code — such as NFPA70, the Canadian Electrical Code (CSA No 22.1), IEC 60364, or BS7671, depending on the installation region — and all applicable requirements of the serving electric utility company and the authority having jurisdiction.

 ☐
5.

The installation site meets the drainage, ventilation guidelines, and clearances given in the Express Solo Site Design Guide.

 ☐
6.

Sufficient space is available to use a forklift or other lifting equipment, unpack, remove packing materials, and allow two people to freely move throughout the site.

 ☐
7.

The anchor bolts, conduits, and concrete pad meet the requirements listed below:

  • The anchor bolts are installed, extend 127 mm (5 in) above the concrete pad, and are vertically plumb.

  • The conduits or armored cables are laid per the conduit layout given in the Express Solo Site Design Guide.

  • In regions that use conduits, the conduits do not have bell ends, are vertically plumb, and stub up to a height of 13–25 mm (0.5–1 in) above the concrete pad. Conduits with bell ends may interfere with tolerances inside Express Solo.

  • The concrete pad is fully cured and smooth.

 ☐

Check Electrical Readiness

Refer to the Express Solo Datasheet and Express Solo Site Design Guide at ChargePoint Product Reference Documentation for electrical input and output specifications.

Required Tools and Materials

Installing Express Solo requires at least two people. Additionally, the installer must bring the following tools and resources. These are not provided by ChargePoint.

Comply with these guidelines to prevent component damage.

  • Use tools suitable to torque metric fasteners. All fasteners used on Express Solo are in metric sizes.

  • Use the given torque values to tighten the fasteners.

  • Ensure that the tools such as torque tool, multimeter, and Ethernet tester are calibrated.

Tools and Materials

Orange and white icon that represents a tool or action.

Construction crane

  • For standard installation

  • Rated for 1450 kg (3197 lb)

Orange and white icon that represents a tool or action.

Forklift with anti-slip forks

  • For low clearance installation

  • Rated for ≥ TBD kg (TBD lb)

  • Fork specifications:

    • Width = TBD mm (TBD in)

    • Thickness ≤ TBD mm (TBD in)

Orange and white icon that represents a tool or action.

Stepladder

Orange and white icon that represents a tool or action.

Industrial vacuum cleaner

Orange and white icon that represents a tool or action.

Wire brush (to remove any residue on anchor bolts)

Orange and white icon that represents a tool or action.

Safety glasses

Orange and white icon that represents a tool or action.

Hard hat

Orange and white icon that represents a tool or action.

Cut-resistant gloves

Orange and white icon that represents a tool or action.

Cable puller or fish tape

Orange and white icon that represents a tool or action.

Measuring tape or other tool to measure linear dimensions

Orange and white icon that represents a tool or action.

Level

Lockout/Tagout equipment

Multimeter (meter and probes rated for 1000 V)

Orange and white icon that represents a tool or action.

Ethernet tester such as a Klein Tools VDV526-052 VDV LANClosed Local Area Network Scout Jr. Tester or similar

Orange and white icon that represents a tool or action.

Conduit cutter (refer to site plans for conduit sizes)

Orange and white icon that represents a tool or action.

Box cutter

Orange and white icon that represents a tool or action.

  • Wire cutters

    		•

    Orange and white icon that represents a tool or action.

    Wire strippers

    Orange and white icon that represents a tool or action.

    Lug crimping tool and die

    Orange and white icon that represents a tool or action.

    Ethernet (RJ45) connector crimping tool

    Orange and white icon that represents a tool or action.

    Torque wrench

    Orange and white icon that represents a tool or action.

    Torque screwdriver

    Orange and white icon that represents a tool or action.

    Shallow socket set (8 mm, 10 mm, 13 mm, 17 mm) and 30 mm deep socket

    		Socket extender

    Orange and white icon that represents a tool or action.

    Hex wrench set

    Orange and white icon that represents a tool or action.

    Torx screwdriver (T20, T30)

    Orange and white icon that represents a tool or action.

    T25 Security screwdriver

    Orange and white icon that represents a tool or action.

    Flathead screwdriver set, including 2 mm, 3.5 mm and 5 mm tip for terminal blocks

    Orange and white icon that represents a tool or action.

    Phillips head screwdriver set

    Orange and white icon that represents a tool or action.

    Torque paint pen

    Orange and white icon that represents a tool or action.

    Permanent marker

    Orange and white icon that represents a tool or action.

    Anti-oxidant joint compound (to make gastight joint between wire and lug) and wire pulling lubricant

    Orange and white icon that represents a tool or action.

    Dielectric grease

    Orange and white icon that represents a tool or action.

    Duct seal compound

    Orange and white icon that represents a tool or action.

    Cable ties

    Orange and white icon that represents a tool or action.

    Paper towel roll


    Cling film (plastic wrap)

    Orange and white icon that represents a tool or action.

    Smartphone with:

    • Internet connectivity

    Orange and white icon that represents a tool or action.



    • ChargePoint installer login credentials

    Orange and white icon that represents a tool or action.

    Orange and white icon that represents a tool or action.

    • ChargePointInstaller app



    Wires and Terminations

    Gather all wires and wire terminations required for the installation project. Refer to the Express Solo Site Design Guide for general system wire specifications and refer to the site plan for wires and terminations required specifically for the installation project.

    Packaging

    Use the following information to transport product packages to the installation site and unpack Express Solo.

    General Instructions and Notes

    The crate is heavy and can cause injury or death if dropped. Do not stand or walk beneath the crate while it is being lifted. Take precautions against the crate tipping or sliding.

    Always transport and store components in their original packaging. Use appropriate lifting equipment (forklift or crane, lifting straps, and any corresponding attachments and accessories). Ensure the load rating of all lifting equipment is adequate for the weight of the crated components.
    Keep components in original packaging, free of moisture, and protected from damage until you install or service them at the site. Store all shipments of components in a dry covered location and protect from moisture.
    To protect the charging cables from damage, keep them wrapped throughout the installation process.

    Leave components in the shipping crate until needed. When removing, protect them from damage (such as scratches) by placing them flat on a blanket or tarp, face up. Do not stand up cover panels, as they may be knocked or blown over. Cover charging connectors to prevent damage or ingress.

    Keep components out of direct sunlight in a cool area until you install them.

    Package Dimensions and Weights

     Express Solo Package Dimensions and Weights

    Package

    Dimensions (L x W x H)

    Max. Weight

    Express Solo

    (Product assembly on shipping pallet)

    1.12 x 1.32 x 2.5 m

    (44.1 x 51.8 x 98.4 in)

    1450 kg (3197 lb)

    Cable Landing Jig

    TBD

    TBD

    Overhead CMKClosed Cable Management Kit

    0.45 x 0.40 x 0.18 m

    (17.50 x 15.88 x 7 in)

    12 kg

    (25 lbs)

    Express Solo Package

    After uncrating Express Solo, check for the following components:

    For any missing component, contact ChargePoint.

    1. Express Solo assembly

    2. Charging cables (Up to x2, depending on configuration)

    3. Hardware box with:

      1. Eye bolts (x4) - Enables lifting of the assembly

      2. Lifting straps (x2) - Enables lifting of the assembly

      3. Keys (x2) - Opens the front, intake (left) and exhaust (right) doors

      4. M20 anchor nuts (x4) - Secures the assembly to foundation

      5. M10 nuts (xTBD) - Secures AC input, external DC output, and DC BUS wires to bus bars

      6. Door lock plugs (x3) - To plug the door locks at completion of installation

    Cable Landing Jig Package

    Unpack the Express Solo Cable Landing Jig package and check for the following components:

    For any missing component, contact ChargePoint.

    1. AC cable jig components

    2. DC cable jig components

    3. Jig alignment plate

    Overhead CMK Package (Option)

    Check the overhead CMKClosed Cable Management Kit package for the following components:

    For any missing component, contact ChargePoint.

    Labeled diagram of product, tools or parts.

    1. Mounting bracket

    2. Overhead CMKClosed Cable Management Kit

    3. Hardware kit with M8 hex nuts (x4) and M6 Torx screws (x4)

    Disconnect Power

    To disconnect power, complete the following steps:

    Risk of shock
    • Before any procedure, disconnect the power.
    • Follow local code and site lockout/tagout procedure to de-energize the station.
    • Wait for energy to dissipate (approximately five minutes).
    • Keep power off until all covers and panels are reinstalled and the work is complete.
    Failure to follow these instructions can result in serious injury, loss of life, or property damage.

    1. Disconnect power at the site electrical panel.

      Follow standard practice and local code to de-energize the applicable circuit and lock out/tag out the disconnect before proceeding.

      Technical illustration depicts the procedural step.

    2. Use a multimeter to test that the unit is de-energized.

    Do not reconnect the power after completing physical installation. An authorized commissioning partner will commission, power on, pinpoint, and configure Express Solo after physical installation.
